Kicker CS-Series 5×7-inch Component Speakers – 46CSS684
CS-Series 6×8-inch Component Speakers are the perfect factory upgrade when you have a separate woofer and tweeter.
CS-Series components include separate titanium tweeters and two-way crossovers with tweeter level control to let you customize your sound for the best sonic quality. The result is precise control with stunning musical realism. Use the flush, angled or surface-mount tweeter pods to perfect your imaging with a sophisticated new look.
These CS-Series speakers work best with 75 watts of recommended power. See below for more details.
Fits nearly every car made
12dB crossovers with a smaller footprint for easier installation
Three-position tweeter switch for dialing in your highs
EVC™ (Extended Voice Coil) technology help deliver remarkable bass response
Titanium tweeter construction and neodymium magnets to reveal subtle details
UV-treated poly-foam surround assists with precise linear excursion
Phase plugs in the woofer cones eliminate any distortion
Steel mesh grilles protect your drivers
Three tweeter mounting options including flush, angled and surface pods
- Woofer Size | in [mm]
6×8 [160×200] - Tweeter Size | in [mm]
3/4 [20] - Dome Material
Titanium - Peak Power | Watts
225 - Continuous Power | Watts, RMS
75 - Effective Frequency Range | Hz
40-21k - Woofer Mounting Hole Diameter | in [mm]
5 x 7 3/16 [126×182] - Woofer Bottom Mount Depth | in [mm]
2 3/16 [56] - Flush Mounting Tweeter Hole Diameter | in [mm]
1 9/16 [40] - Flush Mount Tweeter Depth | in [mm]
9/16 [14.5] - Grilles
No - High Pass | dB, at Frequency | Hz
12, 4000 - Low Pass | dB, at Frequency | Hz
12, 4000 - High Frequency Output Attenuation | dB
0, 3, & 6
