Description
Kenwood Dash Camera with Simplified ADAS Solution
2-way communication with compatible KENWOOD high-end models.
Connects to compatible KENWOOD Multimedia receivers
Dash Cam ready receivers are compatible with the DRV-N520 Dash Camera.
The camera records in full HD video capturing every event that occurs on the road ahead, and also provides safety features such as collision avoidance.
Touch Control
Recorded videos can be displayed on the large screen, and operated from the touch panel.
3 Megapixel Recording
3 Megapixel Recording provides higher resolution than Full HD (1920 x 1080).
HDR (High Dynamic Range) for Backlighting
Easily records clear images in dark or well lit environments without underexposing or overexposing the image.
Equipped with wide-angle lens
The wide-angle lens (horizontal: approx. 117°; vertical: approx. 63°) captures video from a broad viewing perspective.
Advanced Driver Assistance System for Safer Driving
Equipped with the latest in accident avoidance sensor technology.
Collision Warning:
Sensors detect the distance between your car and the vehicle ahead of you, and if a safe distance is not maintained a warning will sound. Collision Avoidance works at 20 MPH and up.
Lane Departure Warning:
Sensors scans the road ahead, recognising the dotted- or straight-line lane markings to the left and right of your car. Should you begin to stray onto or over the lines a warning will sound.
(The accident avoidance features are for providing safety support to drivers and in no way, shape or form is meant to substitute a drivers full attention to the responisbilities of driving. The features do not provide notification of all hazards encountered on the road.
*ADAS function uses the image processing technology commonly used in a digital camera, and its operating accuracy is realized only within the limits of the technology. It may not work as intended in some situations.)
Super Capacitor
Prevents the recorded video file from being corrupted due to lost power, as it provides enough power to allow the video file to close properly.
4 types of recording mode
Continuous recordings:
Recording starts as soon as the vehicle starts. In continuous recording mode. The oldest files are deleted when storage capacity has been exceeded.
Manual recording:
Pressing the Rec button on the device takes the camera out of continuous record mode. The recording time of manual recording is 10 seconds before the manual recording button was pressed plus the time set for “Manual Recording Time.”
Event recording:
When an event such as a collision occurs during continuos recording “Event Recording” automatically starts record of the event. The recording time of event recording is 10 seconds before the event was detected plus the time set for “Event Recording Time.”
Parking recording:
When the vehicle is parked and turned off, parking recording mode becomes active. If the vehicle is subject to a collision, or similar event, power is supplied to the camera and parking recording starts. When recording ends, parking record status resumes.
Built-in G-Sensor
When the G-Sensor detects any sudden motion, DRV-N520 will automatically save and lock the recording to protect it from being deleted. The integrated 3-axis sensor records G-force which shows the direction and the strength of possible impact.
