Description

Autobacs 5″ High Res Monitor (HD5130)

A High Resolution 12/24V monitor kit that offers a clear image and enhanced view when reversing. Its Heavy-Duty construction makes it suitable for trucks, machinery and vehicles. The HD5120 also has the added flexibility of connecting up to 2 cameras.

5” Monitor Specifications:

• TFT Panel: New Grade A LCD
• LCD Size: 5-Inch Diagonal
• Display Format: 16:9
• Resolution: (1024 x 600)
• Brightness: < 500 CD/M2
• Viewing Angles: 70° Left/Right/Up/Down
• Video System: Auto PAL/NTSC Select
• Video Connect: (2 x 4-Pin Male)
• Compatibility: Standard & High Resolution Cameras
• Buttons: Touch Sensitive
• Connection Type: Universal Standard 4-Pin Configuration (M)
• Camera Triggers: 2
• Monitor View: Normal/Mirror/Flip/Mirror-Flip Image Select
• Guidelines: Selectable On/Off
• Audio: Internal Speaker
• Operating Temp: -20°C to +70°C
• Power Input: 10-32V DC (Negative Ground)
• Dimensions: 132.2W x 94.3H x 22.45D mm (Excluding bracket & Visor)
